1800W Vacuum Sealing Machine Pouch Cell Pilot Line Equipment

Description
Color: Black Or Customize Powe Supply: AC220V/50Hz.110V/60Hz Or Customize
Vacuum Pump Capacity: ≥30m³/h Power: 1800W
Gas Source: 0.5~0.8MPa Argon, Nitrogen Cylinder, Or 0.7MPa Compressed Air Function: Pouch Cell Vacuum Presealing
High Light:

1800W Pouch Cell Pilot Line

,

vacuum sealing machine 50Hz

,

AC220V Pouch Cell Pilot Line

Pouch Cell Pilot Line Equipment Vacuum Sealing Machine Pouch Cell Vacuum Sealer

This equipment is mainly suitable for vacuuming and hot-pressing packaging of flexible packaging (medium and small size) lithium batteries after liquid injection and standing; the head is made of copper material, which has good heat transfer effect, saves power consumption and improves work efficiency. Compared with similar products, it is more energy-saving; the pressure of the upper and lower heads can be adjusted by the pressure regulating valve to meet the requirements of different process parameters.

name Parameters Remarks
Upper/lower mold temperature up to 250°C Free temperature setting
degree of vacuum The highest is not lower than -95KPa adjustable
sealing time 0-99s adjustable
Edge time It is recommended to use 3~4s
Edge thickness 0~0.5mm
edge length 290mm
Sealable battery size Max L280mmxW280mm With air bag, with tabs
Edge width Max.6mm (5mm standard) Customized according to customer needs





1800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 01800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 1

1800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 21800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 31800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 41800W Vacuum Sealing  Machine Pouch Cell Pilot Line Equipment 5
