Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine

Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine
Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine

Large Image :  Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine

Product Details:
Place of Origin: China
Brand Name: Gelon
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 30000usd-40000usd
Packaging Details: Standard export package
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1 set /month
Contact Now

Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine

Description
Certification: CE Product Name: Pouch Cell Assembly Equipment
Name: Automatic Winding Machine Application: Cylinder Cell Electrode Winding
High Light:

Cylinder Cell Pouch Cell Assembly Equipment

,

Gelon automatic winding machine

,

electrode winding Pouch Cell Assembly Equipment

Pouch Cell Assembly Equipment automatic winding machine for cylinder cell



Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 0

Automatic Winding Machine for Cylinder Cell and Pouch cell Prismatic Cell

The equipment is used for automatic winding of digital lithium battery core, which is one of the key equipment of battery production. adopt three-winding needle and three-station winding, Coordination of equipment operation, fast winding speed, the failure rate is low. uses the servo system to closed loop control the positive and negative electrode and separator tension, realizing the coil-by-turn tension during the winding process, effectively preventing the deformation of battery core’s the latter process.
The PLC interface design is humanized and scientific, and can display the fault location.

Accuracy

±0.3mm

Production efficiency

≥10PPM

Suitable cells size

T: 2-10mm
W:40-100mm
H: 40-160mm

Electrode length

800-2500mm

Air source

0.5Mpa

Operation Ratio

≥95%

Size

2500mm*1700mm*1350mm

Yield rate

≥98%

Winding needle number

Three

Power Supply

380V 50Hz

Air flow

100L/min

Environmental temperature

-40°~+45°

Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 1Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 2

Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 3
Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 4
Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 5
Cylinder Cell Pouch Cell Assembly Equipment Automatic Winding Machine 6
