Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine
Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine

Large Image :  Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-S100F
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD2340-2740/PCS
Packaging Details: wooden case
Delivery Time: 15-30days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500pcs/month

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine

Description
Product Name: Pneumatic Al Laminated Film Forming Machine Forming Size: Max.L90*W50mm
Forming Pressure: Max. 1T Power: 100W
Molding Accuracy: ±0.05mm Punching Depth: Max. 6mm
Forming Thickness: 0.1~0.2mm Aluminum Plastic Film
Highlight:

Battery pouch cell case forming machine

,

Aluminum Laminated Film Forming Machine

,

6mm pouch cell case forming machine

Battery Lab Aluminum Laminated Film Forming Machine Pouch Cell Case Pouch Cell Assembly Equipment



1. Equipment function: The Al laminated film forming machine is specially designed for the forming of lithium pouch cell case forming . Different forming molds can be customized according to customer requirements ,to realize the case forming of pouch cell of different sizes, and has high safety performance , convenient to replace the mold and easy to maintain.

2. The working principle of the equipment: the use of high-precision molding double force cylinder, drives the mold to rise, the work reaches the set range, and the lower mold returns to the original after the punching is completed.



Features

1. Sheet aluminum laminated film forming, suitable for R&D and sample preparation applications.

2. The molded product is stretched evenly, with high-quality stretching effect, and no defects such as strain or rupture.

3. Driven by cylinder, the forming pressure is adjustable.

4. The discharge port is protected by a safety grating for safe operation.

5. A set of standard size molds are included, and can also be made according to customer requirements.





Model GN-S100F
Forming size Max.L90*W50mm
Punch depth Max. 6mm
Forming thickness 0.1~0.2mm aluminum plastic film
Molding accuracy ±0.05mm
Power supply AC220V/50Hz.AC110V/60Hz
Weight about 110Kg



Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 0

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 1



Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 2



Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 3

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 4

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 5

Battery Pouch Cell Case Forming Machine Aluminum Laminated Film Forming Machine 6
