Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $1,800.00 - $3,500.00/ set
Packaging Details: Standard exported package : Internal anticollision protection, external export wooden box packaging.
Delivery Time: 10-15days
Payment Terms: T/T, L/C, D/P, D/A
Supply Ability: 1000set/month

Battery Pouch Cell Battery Assembly

Description
Type: SEALING MACHINE Applicable Industries: Energy & Mining, Lithium Ion Battery
Condition: New Application: Battery Industry
Automatic Grade: Semi-automatic Weight: 55 KG
Sealing Side Thickness: 0.15-0.3mm(according To Al Laminated Film) Applicable Standard Side Sealing: ≤200mm (Bag Containing)(can Custom)
Lower Mold Temperature:: Standard 160℃-180℃(temp Free Control) Compressed Air: ≥5-8kg/cm2
Top Sealing: ≤200mmBag Containing)(can Custom) Sealing Head Length: ≤200mm (can Custom)
Sealing Time Standard 2S-3S(0-99s Adjust): Standard 2S-3S(0-99s Adjust)
High Light:

Battery Pouch Cell Battery Assembly

,

Top And Side Heating Sealing Machine

,

Pouch Cell Battery Assembly Semi Automatic

Gelon 2022 Newest R&D Pouch Cell Top and Side Heating Sealing Machine for Pouch Cell Battery Assembly

Product Description



Application: heating sealing for top and side sealing before electrolyte filling process


Working principle

It adopts thermal conductivity used on lithium battery packing materials(Aluminium-plastic film),heating it to make it jointing together.The resistance heating pipe transfer the heat source to sealing head(special made from Copper),then transfer it to aluminium-plastic film under press.The temperatrure can be adjusted and kept by thermocouple and thermostat.



Parameter



Name Model/Spec Name Model/Spec
Suitable size ≤200*200*12MM Dimension 450×300×400MM
Production capacity 600EA/H Weight 37KG
degree of parallelism of sealing head ±0.01mm Input power supply AC220V 50HZ
Sealing width 8MM Power 1.0KW
Temperature error ±2°C Input air source 0.6Mpa
Compressed air pipe diameter Φ8MM RH 20~90%RH
suitable thickness of aluminium film 0.1-0.3MM Current temperature 10~35°C
Sealing method Soft sealing



Battery Pouch Cell Battery Assembly 0Battery Pouch Cell Battery Assembly 1Battery Pouch Cell Battery Assembly 2



Battery Pouch Cell Battery Assembly 3Battery Pouch Cell Battery Assembly 4Battery Pouch Cell Battery Assembly 5
