Lithium Battery Production Equipment Single Needle Spot Welder

Large Image : Lithium Battery Production Equipment Single Needle Spot Welder

Product Details:

Place of Origin:	China
Brand Name:	Gelon
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	1300 usd/set
Packaging Details:	standard packing
Delivery Time:	10-15days
Payment Terms:	L/C, D/A, D/P, T/T

Contact Now

Lithium Battery Production Equipment Single Needle Spot Welder

Description

Applicable Industries:	Lithium Ion Battery	Machine Type:	Welding Manipulator
Key Selling Points:	Sustainable	Weight (KG):	52kg
Voltage:	220V	Current:	12kva
Dimensions:	400370220cm	Usage:	Lithium Battery Tabs Welding
High Light:	Lithium Battery Production Equipment , Cylindrical Lithium Battery Bottom , Single Needle Spot Welder

Lithium Battery Production Equipment Cylindrical Lithium Battery Bottom Single Needle Spot Welder

Specification

GN-300A the direct-current type spot welder is Our company promotes most newly specially for the high-end spot welding design spot welder, it is Our company since long technology crystallization, designs according to the present overseas most advanced spot welder's principle. Uses the microcomputer monolithic integrated circuit control and the alternating and direct contravariant technology, the performance achieves the resistance welding the apex level. The product is in the lead the domestic colleague level, with the overseas technical synchronization, definitely may substitute for the foreign product, looks like Japanese SEIWA, AVIO, MIYACHI, American UNITEK spot welder serial products and so on.

Input voltage:	AC 220V±10% 50HZ±5%HZ
Output power:	12KVA
The welding current :	00~99 adjusted
Welding time:	00~99 adjustable
Welding lenth:	25mm, wending hight is adjustable
The size for machine( L×W×H):	400×370×220mm
Application:	0.03 mm~0.5 mm metal sheet

Lithium Battery Production Equipment Single Needle Spot Welder 0

Lithium Battery Production Equipment Single Needle Spot Welder 6
