Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision

Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision
Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision

Large Image :  Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-S100F
Payment & Shipping Terms:
Minimum Order Quantity: 1/PCS
Price: USD 2000-2500/PCS
Packaging Details: Wooden Carton
Delivery Time: 4-6 week
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Contact Now

Pouch Cell Electrode Punching Machine with Max. L80*W60mm Punching Size, 0.5mm Thickness, and ±0.1mm Precision

Description
Punching Size: Max. L80*W60mm Punching Thickness: Max. 0.5mm
Standard Die: Cathode56*43mm Anode58*45mm,customized As Request Life Of Cutting Die: About30 Thousand Times(Normal Use)
Installment Size: L370mm*W245mm*H245mm Weight: 32KG
Highlight:

0.5mm Pouch Cell Battery Assembly

,

lithium battery making machine

,

80x60mm electrode punching machine

Aluminum Laminated Film Pouch Cell Battery Assembly Lithium Battery Making
Semi-automatic electrode punching machine designed for cutting cathode and anode electrodes of lithium-ion batteries. This pneumatic system can be operated within glove boxes and offers customizable cutting dies to accommodate various electrode sizes and shapes.
Technical Specifications
Gas Source 0.5~1.0MPa Argon/Nitrogen, or 0.7MPa compressed air (not in glove box)
Maximum Punching Size L80 × W60mm
Standard Die Sizes Cathode: 56×43mm, Anode: 58×45mm (customizable upon request)
Cutting Die Lifespan Approximately 30,000 cycles (normal use)
Punching Pressure Maximum: 1T, For electrode: 500Kg (0.5MPa)
Punching Precision ±0.1mm
Maximum Punching Thickness 0.5mm (aluminum-plastic film)
Punching Stroke 12mm
Installation Dimensions L370mm × W245mm × H245mm
Punching Burr Vertical burr ≤12μm, Level burr ≤20μm
Weight 32KG
Product Gallery
Semi-automatic electrode punching machine front view Electrode punching machine side view showing controls Close-up of cutting die mechanism Punching machine operational view Machine interior and component details Complete electrode punching system setup
