Product Details:
Place of Origin: China
Brand Name: GELON
Certification: CE
Model Number: GN-18650 Battery OCV Sorting Machine
Payment & Shipping Terms:
Minimum Order Quantity: 1/set
Price: USD 10000-15000/set
Packaging Details: Standard Export Package of pouch cell lab line
Delivery Time: 7-15/sky
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10/set/per /moon

18650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line

Description
Product Name: 18650 Battery OCV Sorting Machine Warranty: 1 Year
Core Components: PLC, Engine, Motor, Pump Application: Lithium Ion Pouch Cell Making
After Warranty Service: Video Technical Support, Online Support Port: Qingdao,Shenzhen,Shanghai
Packaging Details: Standard Export Package Of Pouch Cell Lab Line Applicable Industries: Battery Making
High Light:

18650 Battery Assembly Machine

,

battery sorting machine oem

,

Battery Assembly Machine OEM

Battery Pack Assembly Machine 18650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line



The 18650 battery eleven-speed one-measurement sorting machine is suitable for the voltage and internal resistance sorting test of the 18650 battery core which is divided by the battery core factory. The electrical control part of the sorting system adopts modular design, with high integration, good general purpose and convenient maintenance. The actuator adopts stepper motor control with high precision and good reliability. The number of receiving slots of the equipment is 11 slots, and the voltage and internal resistance can be set arbitrarily. The sorting efficiency is high, and the battery can be accurately sent to the specified gear according to the set internal resistance and voltage value. The equipment adopts the silo type loading, the cylinder automatically divides the material, and the personnel manually collects the material. Realize the automation of 18650 cell sorting.

18650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line 0



Products Features:
1. PLC touch operation system,All faults are presented through the computer display, which is convenient and quick to operate.Database management mode, long-term preservation, strong traceability.

2. Automatic loading space, can put 500batteries at a time, so that you no longer worry about the space is not big enough

3. Can be sorted to different grade(6,11,13) according to voltage internal resistance

4.Accuracy internal resistance tester, servo and slide mechanism for high-speed and stable feeding

Power
0.8kw
Production effiency
3500pcs/H
Air source
0.4-0.6Mpa
Battery size
18650/ 26650/ 21700
I-R inspection accuracy
+0.5% rdg
Vlotage inspection accuracy
0.1MV
Size
1540*800*1400mm
Weight
280kg



We have our own lithium ion battery factory who mainly produces lithium ion battery for camera, mobile, EV application. Based on our battery production line, we can offer all services (Raw Materials, Equipments, Production line design &Technology, etc. ) for full set of equipments to help clients to set up Lab & Pilot line for lithium ion battery.



18650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line 1
18650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line 218650 Battery OCV Sorting Machine Battery Assembly Machine Battery Assembly Line 3
