Laboratory Battery Electrode Slot Die and Doctor Blade Coating Machine

1. Product Overview

The Laboratory Battery Electrode Slot Die and Doctor Blade Coating Machine is a precision coating system designed for lithium-ion battery research, electrode material development, and laboratory-scale electrode fabrication.

The machine is suitable for coating battery electrode slurries onto metal current collectors, including aluminum foil for cathode electrodes and copper foil for anode electrodes. It supports electrode coating process development, slurry formulation evaluation, and coating parameter optimization.

Depending on the machine configuration, the system can be equipped with a slot-die extrusion coating head, a doctor blade coating head, or both coating methods. It is suitable for universities, research institutes, battery laboratories, pilot-line development, and battery manufacturers.

2. Main Applications

• Lithium-ion battery cathode and anode electrode coating

• Battery electrode material research and development

• Electrode slurry formulation testing

• Coating thickness and uniformity evaluation

• Battery electrode process optimization

• Small-batch electrode preparation for laboratory testing

• Research on new battery chemistries and electrode materials

3. Technical Specifications

Product Name: Laboratory Battery Electrode Coating Machine

Coating Methods: Slot-die extrusion coating / Doctor blade coating (depending on configuration)

Applicable Materials: Battery cathode and anode slurries

Substrate Materials: Aluminum foil, copper foil, and other compatible flexible substrates

Application: Lithium-ion battery R&D and laboratory electrode fabrication

Coating Width:  Customizable

Coating Thickness Range:  Customizable

Coating Speed:  Customizable

Customization: Available upon confirmation of technical requirements

4. Key Features

Precision Coating

Designed to help achieve uniform electrode slurry distribution and consistent coating quality for laboratory research and process development.

Flexible Coating Configuration

Depending on the selected model, the machine can use slot-die extrusion coating for controlled slurry delivery or doctor blade coating for adjustable wet-film thickness.

Adjustable Coating Parameters

Coating parameters such as coating gap, speed, and slurry delivery can be adjusted according to the machine configuration and experimental requirements.

Laboratory-Scale Design

Suitable for small-batch electrode preparation, material evaluation, and experimental process optimization without requiring a full-scale production line.

Versatile Substrate Compatibility

Designed for use with common battery current collector foils, including aluminum and copper, subject to substrate thickness and machine specifications.

Optional Heating Function

A heating platform or drying module may be available depending on the selected configuration, helping facilitate solvent evaporation and electrode preparation.

5. Working Principle

Slot-Die Extrusion Coating: Battery slurry is delivered through a precision slot-die head and deposited onto the moving substrate. This method is suitable for controlled slurry delivery and repeatable coating processes.

Doctor Blade Coating: Battery slurry is spread across the substrate by a blade with an adjustable coating gap. The wet-film thickness is influenced by the blade gap, slurry properties, coating speed, and other process conditions.

The appropriate coating method depends on the electrode formulation, target coating thickness, substrate, and research objectives.

6. Advantages for Battery Research

• Supports repeatable laboratory coating experiments

• Helps evaluate electrode slurry formulations

• Facilitates coating parameter optimization

• Suitable for different stages of battery material development

• Supports preparation of electrode samples for subsequent drying, calendaring, cutting, and cell assembly

• Can be configured according to specific laboratory requirements

7. Optional Configurations

Depending on the selected model, the following options may be available:

• Slot-die coating head

• Doctor blade coating head

• Heated coating platform

• Vacuum substrate fixing system

• Adjustable coating speed

• Precision slurry feeding system

• Drying oven or integrated drying module

• Customized coating width and platform dimensions

Please confirm the required functions and configuration before ordering.

8. Customization and Technical Support

GELON provides battery research equipment and manufacturing solutions for laboratory research, process development, and small-scale battery production.

Customized configurations can be discussed according to coating width, slurry characteristics, target coating thickness, substrate dimensions, heating requirements, and laboratory operating conditions.

Please contact us for detailed specifications, available configurations, quotations, and technical consultation.
