High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process

High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process
High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process

Large Image :  High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE,ISO9001
Model Number: GN-MR-150H
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $4513
Packaging Details: standard packing
Delivery Time: 35days
Contact Now

High-Precision Heated Rolling Press, Laboratory Calender for Lithium Battery Electrode Calendering Process

Description
Core Components: PLC, Engine Rolling Specification: 300mm
Maximum Working Pressure: 50MPa Roller Gap: 0~1.2 Mm (adjustable)
Highlight:

Heated Rolling Press for Electrode Calendering

,

Laboratory Calender for Lithium Battery Electrodes

,

Pouch Cell Electrode Calendering Equipment

Product Overview

1. This machine is primarily designed for the electric rolling of cathode and anodeelectrode battery materials, as well as n onferrous metals such as copper and aluminum in laboratories. It is particularly suitable for thinning and increasing the
density of lithium battery electrode, which are materials for clean energy.

2.The equipment uses gear transmission to achieve roller pressing, with adjustable pressing thickness and convenient use. The rollers have high hardness and are treated with hard chrome plating on the surface, reaching a hardness of HRC55 and being rust-resistant, ensuring safe use.

3.The wedge adjustment for the pressing gap is stable and has high adjustment precision. The rolling precision is high,
facilitating the feeding of sheet materials for rolling. It uses gear engagement to achieve roller pressing. The pressing
thickness and speed are adjustable. Electric roller pressing forms automation and allows for forward and reverse operation.

4.The upper and lower rollers have independent temperature control.

Tag:

Aluminum Laminated Film Forming Machine,

Lithium Battery Pouch Cell Assembly Equipment,

Small Pouch Cell Assembly Equipment
