Auto Crimper Coin Battery Research Electric Crimping Machine Sealer

Auto Crimper Coin Battery Research Electric Crimping Machine Sealer
Auto Crimper Coin Battery Research Electric Crimping Machine Sealer Auto Crimper Coin Battery Research Electric Crimping Machine Sealer Auto Crimper Coin Battery Research Electric Crimping Machine Sealer Auto Crimper Coin Battery Research Electric Crimping Machine Sealer

Large Image :  Auto Crimper Coin Battery Research Electric Crimping Machine Sealer

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-CC20
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD1536-2209/PCS
Packaging Details: wooden case
Delivery Time: 15-30days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500pcs/month

Auto Crimper Coin Battery Research Electric Crimping Machine Sealer

Description
PProduct Name: Coin Cell Crimper Sealing Pressure: Min.80Kg, Max.1400Kg
Sealing Beat: 14 Seconds/set (refer To CR2032 Battery) Usage: Coin Cell Sealing
Weight: About 35Kg Sealing Mold: According To Customer Requirements
Sealing Stroke: 30mm
High Light:

Auto Crimper Coin Battery Research

,

electric crimping machine CE

,

CR2032 battery coin cell crimper

Battery Electric Crimping Machine Sealer Auto Crimper Coin Battery Research



Product Description:

This equipment is mainly driven by motor,After putting the battery in the mold, click the start button, and the lower mold
automatically rises,When the pressure reaches the set pressure, the lower die rises automatically.In the process, the battery sealing is formed. This crimping machine mainly uses for sample making of coin cell in lab battery materials research, capacitor research sealing and can also be used in the factory less batch trial production. Different molds can also be used for dry powder pressing, wet powder pressing, nickel foam pressing, pressing molding, riveting and so on.



Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 0

Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 1Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 2



Product name Coin Cell Crimper
Sealing pressure Min.80Kg, Max.1400Kg
Sealing stroke 30mm
Pressure accuracy ± 1.5%
Sealing mold according to customer requirements
Optional or add CR16, CR20, CR24, CR30 and other specifications
Power 500w
Warranty

1 year





We can supply:



1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.

2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.



Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 3



Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 4

Auto Crimper Coin Battery Research Electric Crimping Machine Sealer 5
