Product Details:
|
| PProduct Name: | Coin Cell Crimper | Sealing Pressure: | Min.80Kg, Max.1400Kg |
|---|---|---|---|
| Sealing Beat: | 14 Seconds/set (refer To CR2032 Battery) | Usage: | Coin Cell Sealing |
| Weight: | About 35Kg | Sealing Mold: | According To Customer Requirements |
| Sealing Stroke: | 30mm | ||
| High Light: | Auto Crimper Coin Battery Research,electric crimping machine CE,CR2032 battery coin cell crimper |
||
Battery Electric Crimping Machine Sealer Auto Crimper Coin Battery Research
Product Description:
This equipment is mainly driven by motor,After putting the battery in the mold, click the start button, and the lower mold
automatically rises,When the pressure reaches the set pressure, the lower die rises automatically.In the process, the battery sealing is formed. This crimping machine mainly uses for sample making of coin cell in lab battery materials research, capacitor research sealing and can also be used in the factory less batch trial production. Different molds can also be used for dry powder pressing, wet powder pressing, nickel foam pressing, pressing molding, riveting and so on.
| Product name | Coin Cell Crimper |
| Sealing pressure | Min.80Kg, Max.1400Kg |
| Sealing stroke | 30mm |
| Pressure accuracy | ± 1.5% |
| Sealing mold | according to customer requirements |
| Optional or add | CR16, CR20, CR24, CR30 and other specifications |
| Power | 500w |
| Warranty |
1 year |
We can supply:
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.
2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.
