Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride

Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride
Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride

Large Image :  Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-PVDF
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: $75-$120/Kilogram
Packaging Details: Standard export package.
Delivery Time: 7-10 working days
Payment Terms: L/C, T/T, Western Union, D/P
Supply Ability: 3000 Kilograms per month

Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride

Description
Production Name: Polyvinylidene Fluoride/PVDF Usage: Lithium Ion Battey Research
MOQ: 1 KG Sample: YES
Shipping: By Sea/Air/Express/Land Supply 1: Lithium Ion Battery Raw Material
Supply 2: Lithium Ion Battery Production Equipment Supply 3: Lithium Solid Battery Raw Material
High Light:

Lithium Ion Battery Materials PVDF

,

Battery binder raw material

,

PVDF Polyvinylidene Fluoride

Battery binder PVDF Polyvinylidene Fluoride Lithium Ion Battery Materials



Polyvinylidene fluoride, or PVDF, is a fluorinated thermoplastic which has outstanding resistance to most mineral and organic acids, aliphatic and aromatic hydrocarbons, alcohols, halogenated solvents, and oxidizing environments. It also has outstanding aging resistance, with its properties remaining constant after many years of continuous use.



Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 0

Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 1

Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 2





PVDF technical specification:



PVDF (Polyvinylidene fluoride ) binder is for mixing together with cathode powder to prepare Li-ion battery electrode , vacuum sealed in the plastic bag.

PVDF (Polyvinylidene fluoride ) binder is for mixing together with cathode powder to prepare Li-ion battery electrode , vacuum sealed in the plastic bag.

Product name PVDF Type PVDF-9300
Test item Value Test method Test condition
Physical properties Appearance White powder Visual inspection Dustless

g/cm3

Standard relative density

1.75-1.77 D792 @23/23

%

Rate of water content

≤0.10 D570 110,0.09MPa,1.5h

Melting point

160-170 D3418 -
Refractive index 1.42 D542 at Sodium D line,23
Molecular weight, ×104 100 or so GPC inspection -
Thermal properties

-1

Coefficient of linear thermal expansion

≤13×10-5 D696 -

Deflection temperature

125-140 D648 at 454 kPa
Flammability

%

Limiting oxygen index

43 D2868 -

Thermal decomposition temperature

≥380 TGA 1wt loss,N2









Full Automatic Car Battery Production Line/ Electric Vehicle Battery Production Line/Li Ion Battery Plant Equipment

Integrate China's top materials manufacturer,Gelon can supply full set of raw materials solution for Lithium ion battery .Our preponderant products are LFP,LMO,LCO, NMC,NCA; LTO,MCMB, natural graphite,Separator ,Electrolyte& Other accessories (SBR CMC NMPPVDF,Sup-Li,Al&Ni Tabs ,and battery packs tags.,etc ) for new power lithium ion batteries.
Based on our extensive batteryproduction experiences and battery equipments factrories,we can design and offer turn-key solution for customer, and indertakelithium ion battery project design, construction&training .
By now,Gelon group has successfully supplied automatic equipments formany well-known battery manufacturers,such as TESLA ,LG,SONY,ATL ......; also successfully offered turn-key projects in Bolivia,Argentina,United Kingdom,Russia,Turkey, Thailand,Indonesia,Indian,South Africa ....

Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 3Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 4

We can supply:


1.) full set of lithium battery materials,including :
LiMn2O4, LTO, NCA, LiNiMnCoO2(NMC), LiCoO2, Graphite(MCMB) and other cathode&anode battery materials; Alumimun foil, copper foils, battery separator, etc.


2.) full set of lithium battery equipments, for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.


3.) full set of lithium battery technology:
We can design the laboratory and production line,according to customer's request.



Battery Binder Lithium Ion Battery Materials PVDF Polyvinylidene Fluoride 5
