Product Details:
|
| Source Voltage: | Single Phase 220VAC±10%(Customizable 110VAC/60Hz) | Sealing Pressure: | Min.80Kg, Max.1400Kg |
|---|---|---|---|
| Sealing Stroke: | 30mm | Pressure Precision: | ±1.5% |
| Frequency & Powder: | 50Hz, 500W | NAME: | Sealing Machine |
| High Light: | Single Phase Coin Battery Research,pneumatic punching machine,Coin Battery Research CR2016 |
||
Gelon Lab Equipment For Coin Battery Research CR2016 CR2032
Technical Parameter
| 1.Source voltage: single phase 220VAC±10%(Customizable 110VAC/60Hz), frequency: 50Hz, power: 500W |
| 2.Sealing pressure: Min.80Kg, Max.1400Kg |
| 3. Sealing stroke: 30mm |
| 4. Pressure precision: ±1.5% |
| 5. Sealing cap beat 14 s / unit (refer to CR2032 battery) |
| 6.The sealing die CR20 series sealing mold is optional and can be customized according to the requirements of the customer |
| 7. Disassembly die:Various specifications, such as CR16,CR20,CR24,CR30, etc., can be selected or added. |
| 8Weight: about 35Kg |
