Product Details:
|
| Working Type: | Manual | Product Name: | Coin Cell Crimping Crimper Machine |
|---|---|---|---|
| Sealing Pressure: | Min.80Kg， Max.1400Kg | Sealing Stroke: | 30mm |
| Pressure Accuracy: | ±1.5% | Sealing Mold: | Cr20XX |
| Net Weight: | About 27kg | Equipment Size: | About L270*W290*H340mm |
| Highlight: | CR20XX Coin Battery Research,Coin Cell Hydraulic Crimper Machine,Coin Battery Research Hydraulic |
||
CR20XX Hydraulic Lithium Coin Cell Crimping Crimper Machine
Equipment features
1.Adopt special hydraulic structure, high pressure, easy operation.
2.High precision sealing, easy to operate.
3.The button cell of different specifications can be sealing and disassembled with different moulds.
4.It has the advantages of small size, convenient operation and precise molding .
| Name | Specs | Note | ||||||||||||||||||||||||||||||||||||||||||
| Sealing pressure | Min.80Kg, Max.1400Kg | The battery pressure of different diameters can be adjusted. The best pressure for CR20 series will be set if without special requirements: 50kg/cm2~60kg/cm2 | ||||||||||||||||||||||||||||||||||||||||||
| Sealing stroke | 30mm | |||||||||||||||||||||||||||||||||||||||||||
| Pressure accuracy | ±1.5% | |||||||||||||||||||||||||||||||||||||||||||
| sealing efficiency | 20second/pcs | Refer to CR2032 cell | ||||||||||||||||||||||||||||||||||||||||||
| Sealing mold | CR2032 for standard | Others can be customized | ||||||||||||||||||||||||||||||||||||||||||
| Disassmbling mold | CR2032 for standard | Others can be customized | ||||||||||||||||||||||||||||||||||||||||||
| Working type | Manual | Can be in glove box | ||||||||||||||||||||||||||||||||||||||||||
| Equipment size | About L270*W290*H340mm | |||||||||||||||||||||||||||||||||||||||||||
| Packing size | About L380*W300*H440mm | |||||||||||||||||||||||||||||||||||||||||||
| Net weight | About 27kg | |||||||||||||||||||||||||||||||||||||||||||
| Gross weight | About 38kg | |||||||||||||||||||||||||||||||||||||||||||
| Using field | can use in the glove box freely. For details, check whether the space of the glove box matches the external size of the device | |||||||||||||||||||||||||||||||||||||||||||
| Warranty | One year limited warranty with lifetime support |
|
We also could supply all materials and full sets equipments for Li-ion battery.
1.)full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.
2.)full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutting machine --winding machine--sealed machine,etc
3)full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request
