Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research

Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research
Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research

Large Image :  Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1square
Price: $1.00 - $3.00/ square meter |1 square meter/square meters(Min. Order)
Packaging Details: Standard exported package : Internal anticollision protection, external export wooden box packaging.
Delivery Time: 15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000square

Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research

Description
Warranty: 3months-1year Battery Size: Lithium Ion Battery
Model Number: GN-Separator Weight: 3kg/roll
Appearance: White Thickness: 5um To 25um Customize
MD Tensile Strength: ≥150 Material: PE /PE Or Multi Layers
Use For: Battery Seperator Type: PP Or PE Or Ceramic Coated
Width: Customize
High Light:

Sodium Na ion Battery Separator

,

Coin cell Battery Raw Materials

,

lithium ion battery separator

Sodium Na ion Battery Separator Battery Raw Materials for Coin cell Battery ResearchProduct

Product Description

PE PP PP/PE/PP Multi layers Battery Separator with Customized Width

PE & PP separators are used for lithium-ion battery manufacturers and researchers. The materials consist of Polymer film , that are either Polypropylene (PP) or Polyethylene (PE) based. contain micro and nano pores to provide excellent ion transportation capabilities within the li-ion battery.

Also Ceramic-coated variety for enhanced thermal deformation resistance and mechanical strength.
Specification
No.
Test Term
Unit
Inspection value
1
Thickness
micron
20.0±2.0
2
Surface density
g/㎡
17.0±2.0
3
Ceramic layer Surface density
g/㎡
8.0±1.5
4
Gas permeability
Sec/100ml
250±40
5
Gas permeability increment
%
≤15%
6
Puncturing Strength
gf
≥580
7
120℃ *1h shrinking percentage
MD
%
≤2.0
8
TD
%
≤1.5
9
Tensile strength
MD
Mpa
≥150
10
TD
Mpa
≥135
11
Tensile
Elongation
MD
%
≥50
12
TD
%
≥50
13
Film close temperature
≤135
14
Width
mm

15
Length
m

16
Peel strength
N/m
≥40
17
Static electricity
KV
≤2.0
18
Water content
ppm
≤1200



Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 0Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 1Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 2Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 3Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 4

Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 5Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 6Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 7Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 8Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 9Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 10Sodium Na Ion Battery Separator Battery Raw Materials For Coin Cell Battery Research 11
