Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One

Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One
Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One
Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One

Large Image :  Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-ZY3500
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 80000-200000USD
Packaging Details: wooden box package
Delivery Time: 3months
Payment Terms: L/C, T/T
Supply Ability: 30sets one month

Lithium Ion Battery Assembly Line Automatic Cylinder Cell Assembly Line All In One

Description
Product Name: Automatic Cylinder Cell Assembly Line Materials: Stainless Steel
Feature: Automatic Application: Lithium Ion Battery
Voltage: 380,can Be Customized Advantage: High Efficiency And High Quality
High Light:

lithium ion battery assembly line

,

Cylinder Cell Assembly Line

,

battery assembly line automatic

Lithium ion battery automatic cylinder cell assembly line all-in-one machine

Introduction:

It is mainly used for cylindrical lithium battery automatic puting of the bottom insulator , battery core detection, putting battery core in the cases, automatic welding bottom, automatic puting top surface insulator, automatic grooving and coating, automatic laser welding caps, and welded caps , placed in the box.



Features:

1. Automatic double-station into the shell and puting of the bottom insulator: CCD defective product detection.

2, Automatic point bottom welding and adding the top surface mat, automatic totating needle.

3, Automatic grooving and coating oil , effectively prevent the swell after the grooving, can be added to the groove cleaning function.

4, Automatic laser welding cap , welding cap collect automaticly.

5, The welded caps can be placed in box automaticly.

Index:

Voltage 380V 50Hz Power 15kw
Working pressure 5-7kgf/cm2 Needle diameter 2.0-3.0mm
Insulation sheet thickness 0.20mm Application size 10/14/17/18/21/26/32
Working efficiency 70-80ppm/min Size 8000*1500*1800mm
