PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials

PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials
PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials

Large Image :  PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-PP
Payment & Shipping Terms:
Minimum Order Quantity: 50 sqm
Price: USD 50-150/Roll
Packaging Details: Standard Packing
Delivery Time: 4-6 week
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 SQM Per Month

PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials

Description
Porosity: 38%-44% Thickness: 16, 18, 20, 25, 30 Micron, Etc
Width: Customerization Technology: From Japan, Made In China
MOQ: 50sqm Tensile Strength: More Than 90 MPa
High Light:

16 Micron ceramic coated battery separator

,

18 Micron ceramic coated separator

,

2325 Separator Lithium Battery Materials

PE/PP Separator Ceramic Coated Separator 2325 Separator Lithium Battery Materials

Lithium battery materials--Celgard separator--Li-ion battery separator/membrane
1. Thickness: 16&18&20&25&30&40micron
2. Width: 60mm
3. MOQ: 50Sqm

Specification for 16micron thickness for reference:
TermUnitInspection value
Appearance Ivory-white
Thicknessmicron16± 2
Gas permeabilitySec/100ml350-550
Porosity%38-44
Puncturing Strengthg>300
Tensile strength MDMpa>90
Tensile strength TDMpa>100
Film close temperaturedegree≤ 135
Film break temperaturedegree≥ 147
90 degree heat shrink MD%≤ 3.5
90degreeheat shrink TD%≤ 2
105degree heat shrink MD%≤ 5
105degree heat shrink TD%≤ 3
120degree heat shrink MD%≤ 20
120degree heat shrink TD%≤ 15

Advantages:

High safety: Multilayer membrane efficiently reduces the safety hazards (crystal point, holes…) which are found as defects on single layer membrane; No TD shrinkage, , low MD shrinkage; Perfect heat resistance and anti-oxidant; High puncture strength & mechanical strength , suitable for high/low voltage system.

Good uniformity: Using popular dry & uniaxial stretching process, insure the pore sizes uniformity and well distributed on membrane. The separator has multilayer structure with better thickness uniformity to improve Li-ion battery cycle life.

Excellent air permeability: High porosity, high air-permeability, low sinuosity, suitable for high rate discharging of electric vehicle Li-ion battery.

Various products: Basic separator, Ceramic coated separator, Polymer coated separator, Multifunctional hybrid coating separator, Multi-layer functional coated separator.

PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 0PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 1PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 2PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 3

Thickness 16± 2micron Gas permeability Sec/100ml350-550
Porosity 38-44% Puncturing Strength >300g
Tensile strength MDMpa>90 Tensile strength TDMpa>100
Film close temperature degree≤ 135 Film break temperature degree≥ 147



PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 4PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 5PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 6PE/PP Separator Ceramic Coated Battery Separator Lithium Battery Materials 7
