Battery Equipment Mechanical Shock Tester Shock Testing System Battery Testing Lab

Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab
Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab

Large Image :  Battery Equipment Mechanical Shock Tester Shock Testing System Battery Testing Lab

Product Details:
Place of Origin: china
Brand Name: Gelon
Certification: ce
Model Number: GN-SKT-10
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 42000-9999999/PCS
Packaging Details: Standard exported package : Internal anticollision protection, external export wooden box packaging.
Delivery Time: 25 working days
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500pcs/month

Battery Equipment Mechanical Shock Tester Shock Testing System Battery Testing Lab

Description
Product Name: Mechanical Shock Tester Operating Platform: 250 × 200 Mm
Max. Load: 10KG Peak Acceleration: 20 To 1500G
Pulse Duration: 0.2~18ms Shock Range(N):: 500~155000
Equipment Dimensions: 660 × 700 × 1900mm Equipment Weight: 820 Kg
Power Required: AC 220V±10% 50Hz,2kVA MOQ: 1 Set

Battery Equipment Mechanical Shock Tester Shock Testing System Battery Testing Lab



Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 0



Application:

The shock testing system of BE-SKT series are mainly applicable to shock resistance tests in such fields as electronic products, aerospace, shipping, military industry, automotive parts and transportation. Shock tests in form of half sine wave, final peak saw tooth wave or trapezoidal wave shock tests can be carried out by selecting different waveform generators.



Standard Compliance:

IEC62133;UL1642,UN38.3 and other national and international standards, such as: GB/T2423-2008, GJB150, GJB360, GJB548, UN38.3, IEC-62281, GJB1217, MIL-STD-202F, IEC-68-2-27, MIL-STD-810F, MIL-STD-883E, etc



Main Features:

1.Free drop type shock tester using hydraulic lifting and HP fluid braking;

2.Use of pneumatic-hydraulic boosting and strong friction brake to prevent secondary shock braking;

3.Shock measurement device: single-channel data acquisition, simultaneous acceleration data measurement, storage, report printing, data callback, database management of two channels.

4.Use of rubber module, producing a wide range of half sine pulse with arbitrary action time.

5.Availability for equivalent drop test of packing boxes.



Input channels 2 channels
Sampling frequency 192KHz
Pulse duration 50-1ms
Communication interface USB2.0
Supportive standard ISO, UN38.3, MIL-STD-810, user defined



Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 1Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 2Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 3Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 4Battery Equipment Mechanical Shock Tester  Shock Testing System Battery Testing Lab 5
