Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine

Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine
Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine

Large Image :  Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-4680WM
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $468,000/set
Packaging Details: Standard wooden box for export.
Delivery Time: 15-25 working days
Payment Terms: L/C, T/T, Western Union, D/P
Supply Ability: 5 sets per month
Contact Now

Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine

Description
Production Name: Lithium Roll To Roll Integrated Calendaring/ Slitting Machine Usage: Lithium Ion Battey Research And Production
Power: 120KW Roll Diameter: Φ800*800mm
Roll Hardness: HRC66-68 Max Working Pressure: 400T
Voltage And Frequency: AC380V / 50Hz Incoming Electrode Width: 50-800mm
Correction Accuracy: ≤ 0.1mm Core Components: PLC, Bearing, Motor, Pressure Vessel

Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine

The machine is to roll the positive / negative electrodes after coating continuously through the continuous hydraulic pressure roller machine, evenly calender the electrodes to the thickness required by the process, and then slit it into 2-4 electrodes that meet the technological requirement width, and rewind with alignment.

Incoming electrode width: 50-800mm;
Calendaring accuracy: ≤ ±2um
Width cutting accuracy: ≤ ±0.3mm;
Cutting burrs: Foil: ≤10um, Vertical direction of coating area: ≤7um;
Correction accuracy: ≤ 0.1mm



Roll diameter
Φ800*800mm
Roll hardness
HRC66-68
Max working pressure
400T
Power
120KW
Voltage and frequency
AC380V / 50Hz
Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 0Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 1Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 2Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 1Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 2

Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 1Battery Electrode Slitting Machine Li Ion Battery Making Machine Roll To Roll Integrated Calendaring Slitting Machine 6
