Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-VM-7P
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 1050 USD
Packaging Details: Wooden case
Delivery Time: 25-35 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 500 pcs/month

Gelon 220V Lithium Battery Vacuum Drying Oven with PLC Automatic Control Touch Screen 1-Year Warranty for Research Lab Line

Description
Voltage: 220 V Power(W): 1 KW
Core Components: PLC Warranty: Effective V1 Yearolume Max.400ml
Product Name: Lab Vacuum Oven Voltage Standard: AC220V 50Hz, 110V Can Customize
Applicable Industries: Manufacturing Plant, Laboratory Research After Warranty: Service Video Technical Support
Origin: Guangdong, China Model NO.: DZF6020
Weight: 70 Kg
Highlight:

220V lithium battery drying oven

,

PLC automatic control vacuum oven

,

research lab vacuum drying oven

Gelon Lithium Battery Vacuum Drying Oven


Gelon 220V Lithium Battery Vacuum Drying Oven with PLC Automatic Control Touch Screen 1-Year Warranty for Research Lab Line 0Gelon 220V Lithium Battery Vacuum Drying Oven with PLC Automatic Control Touch Screen 1-Year Warranty for Research Lab Line 1Gelon 220V Lithium Battery Vacuum Drying Oven with PLC Automatic Control Touch Screen 1-Year Warranty for Research Lab Line 2




Contact for details


Email: Kimberley@libgroup.net

WhatsApp/Mobile/Wechat: +86-13686664348


Products Description


Ⅰ.Features

1. Radiant warm wall heating system provides optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.

2. 3" (7.6 cm) glass wool insulation prevents heat loss from working chamber.

3. Silicone door gasket and positive latch door maintain seal at all vacuum levels.

4. Exclusive polycarbonate safety shield protects door glass.

5. Easy-to-clean #304 stainless steel chamber interior.

Vacuum and air lines constructed with corrosion-resistant stainless steel tubing for optimum chamber cleanliness and long term performance.


II. Specifications


 Type

  GN-6020



 Power Supply

  Standard AC220V 50HZ, 110V can customize

 Power

   400W

 Temperature Range

   RT+10~250℃



 Temperature resolution

   0.1℃

 Temperature fluctuation

   ±1℃

 Vacuum

   <133Pa

 Operating ambient temperature

   +5~40℃

 Inner Chamber size(mm)W*D*H

   300*300*275

 Outside size(mm)W*D*H

   605*490*450

 Shelf

   one

 Weight

   About 50kg

 Timing range

   0~9999min

 Studio material

   Stainless steel liner
