Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A

Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A
Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A

Large Image :  Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A

Product Details:
Place of Origin: CHINA
Brand Name: GELON
Certification: CE
Model Number: GN-S300A
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: standard wooden case
Delivery Time: 20-30 DAYS
Payment Terms: T/T,D/A,L/C,D/P
Supply Ability: 50 pcs per month
Contact Now

Semi-Automatic Manual Feed Lithium Battery Electrode Slitting Machine for Lab Use GN-S300A

Description
Slitting Material: Copper Foil, Aluminum Foil, Cathode And Anode Electrodes Slitting Method: Fixed Upper And Lower Roller Slitting
Material Thickness: 15—300um Maximum Width Of Incoming Material: 300mm
Minimum Slitting Width: ≥40mm Slitting Width Accuracy: ±0.1mm
Cutting Knife Life: 5000m/pc Slitting Speed: Adjustable By Electric Speed Controller

Lithium Battery Semi-Automatic Electrode Manual Feed Slitting Machine GN-S300A For Lab

Lithium Battery Semi-Automatic Electrode Slitting Machine GN-S300A
Equipment Introduction
No. Item Description
1 Overview This machine uses a circular cutting knife and roller-style slitting, whose slitting principle is to cut the electrodes by driving the upper and lower slitting knife seats with an electric motor, with manual feeding and automatic blanking. Pre-cut the lithium-ion battery electrodes to the desired length, place the cut electrodes against the feeding guide edge to align them properly, and then gently guide them into the cutting system by hand.
2 Features
  • Sheet-like feeding, upper and lower circular knife cutting method. The slitting knife replacement is more convenient, and adjustment is simpler.
  • Motor-driven, with feeding guidance and small slitting burrs.
  • D2 material slitting knives are treated with heat treatment, resulting in good slitting effect and long service life.
  • Inlet and outlet are equipped with stainless steel receiving plates.
  • The entire slitting knife assembly is enclosed within a protective cover, ensuring safe operation.
3 Notes
  • Before each work session, please carefully wipe both roller surfaces with a dust-free cloth soaked in alcohol to maintain cleanliness.
  • Apply lubricating oil to the gear movement parts to ensure smooth motion.
  • Do not use an air pump for blowing and sweeping to prevent dust from entering the bearings and affecting the precision of use.
  • If not used for a long time, please wipe the roller surfaces clean and spray anti-rust oil on the surface to protect the roller from corrosion.
  • Regularly inspect the screws, nuts, pins, and other fasteners of the machine to prevent malfunctions and accidents caused by loosening.
Equipment Technical Parameters
Name Parameters Remarks
Slitting Material Copper foil, aluminum foil, cathode and anode electrodes
Slitting Method Fixed upper and lower roller slitting
Material Thickness 15-300μm
Maximum Width of Incoming Material 300mm
Minimum Slitting Width ≥40mm Customized
Slitting Width Accuracy ±0.1mm Ensure that the placement is flat, vertical, and the operation is horizontal
Cutting Knife Life 5000m/pc
Slitting Speed Adjustable by electric speed controller
Power Supply AC220V/50Hz (110V/60Hz) Customized
Power 250W
Equipment Dimensions ≈L687×W1058×H348mm Including receiving plate
Size of Wooden Box after Equipment Packaging ≈L770×W330×H500mm Packed up after disassembling the material receiving plate
Net Weight of Equipment ≈140kg
Gross Weight of Equipment ≈156kg
Usage Site
Can be used inside the glove box, please verify if the glove box space matches the equipment's outer dimensions
Warranty Period 1 year
