Lab Hot Rolling Press Machine Lithium Battery Electrode Calender with Adjustable Roller Gap 0~1.2 mm High Hardness Rollers HRC55 and Independent Temperature Control

Large Image : Lab Hot Rolling Press Machine Lithium Battery Electrode Calender with Adjustable Roller Gap 0~1.2 mm High Hardness Rollers HRC55 and Independent Temperature Control

Product Details:

Place of Origin:	China
Brand Name:	Gelon
Certification:	CE
Model Number:	GN-MR-200H Dia 96*200mm width

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	2899-2999 USD
Packaging Details:	Wooden case
Delivery Time:	25-30 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	500 sets/month

Contact Now

Lab Hot Rolling Press Machine Lithium Battery Electrode Calender with Adjustable Roller Gap 0~1.2 mm High Hardness Rollers HRC55 and Independent Temperature Control

Description

Roller Size:	Φ96mm	Roller Gap:	0~1.2 Mm (adjustable)
Roller Width:	250mm	Effective Roller Width:	245mm
Roller Gap Adjustment Precision:	0.01mm	Upper/Lower Roller Heating Temperature:	Recommended Heating Temperature 60℃-80℃
Roller Hardness:	Surface Hardness ≥ HRC55 Hardness Layer Thickness ≥ 10mm	Roller Drive:	Motor-driven
Rolling Speed:	Adjustable	Power Supply:	AC220V/50Hz，110V/60Hz Customized
Power:	2400W	Equipment Dimensions:	≈L880W260H415mm
Net Weight Of Equipment:	Approx. 102kg
Highlight:	Adjustable Roller Gap Lithium Battery Electrode Calender , High Hardness Rollers Lab Hot Rolling Press Machine , Independent Temperature Control Electrode Sheet Compacting Machine

Lab Hot Rolling Press Machine GN-MR-250H

Lithium Battery Electrode Calender for Anode Cathode Sheet Thickness Compacting

Contact for details:
Email: Kimberley@libgroup.net
WhatsApp/Mobile/Wechat: +86-13686664348

Product Overview

This machine is primarily designed for the electric rolling of cathode and anode electrode battery materials, as well as nonferrous metals such as copper and aluminum in laboratories. It is particularly suitable for thinning and increasing the density of lithium battery electrode materials for clean energy applications.

Key Features

Gear transmission system for precise roller pressing with adjustable thickness
High-hardness rollers with hard chrome plating (HRC55 hardness), rust-resistant
Wedge adjustment mechanism for stable gap control with high precision
Forward and reverse calendering operation with adjustable speed
Independent temperature control for upper and lower rollers
Speed regulating motor drive with inlet and outlet guide plates
Automated electric roller pressing system

Technical Specifications

Parameter	Specification	Remarks
Roller Size	Φ96mm
Roller Gap	0~1.2 mm (adjustable)
Roller Width	250mm
Effective Roller Width	245mm
Roller Gap Adjustment Precision	0.01mm
Upper/Lower Roller Heating Temperature	Recommended: 60℃-80℃	Max: 100℃
Roller Hardness	Surface hardness ≥ HRC55	Hardness Layer Thickness ≥ 10mm
Roller Drive	Motor-driven	Suitable for argon gas environment
Rolling Speed	Adjustable
Power Supply	AC220V/50Hz, 110V/60Hz	Customized options available
Power	2400W
Equipment Dimensions	≈L880×W260×H415mm	Including dial indicator
Packaging Dimensions	≈L980×W400×H580mm
Net Weight	Approx. 102kg
Gross Weight	Approx. 124kg
Usage Site	Laboratory/Glove Box	Verify glove box space compatibility
Warranty Period	1-year warranty	Lifetime maintenance
