CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose

CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose
CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose

Large Image :  CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: binder CMC-C3000
Payment & Shipping Terms:
Minimum Order Quantity: 1kg
Price: 15-20USD/kg
Packaging Details: Carton Packaging
Delivery Time: 10 working days after receiving 100% prepayment
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 500 kgs/month
Contact Now

CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose

Description
Appearance: White Powder
Highlight:

CMC battery electrode binder

,

sodium carboxymethyl cellulose powder

,

lithium battery raw material

CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose
Contact for details:
Email: scarlett@libgroup.net
Product Overview



Lithium Battery Raw Material Binder CMC-C3000
The binder is an inactive component in the electrode sheet of the lithium ion battery, and it'smain function is to connect the electrode active material, the conductive agent and theelectrode current collector, so as to have an overall connectivity between the electrode activematerial, the conductive agent and the current collector, thereby reducing the impedance ofthe small electrode. According to the dispersion of the binder in the electrode, it can be divided into point type.line type and body type.
Currently, commonly used binders are : CMC, PVDF, PTFE, SBR, Aqueous binderLA132/133, BAP-L

CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose
CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose

CMC Carboxymethyl Cellulose Sodium Powder Battery Electrode Binder Lithium Battery Raw Material Sodium Carboxymethyl Cellulose









Specification
item
unit
Min. value
Max. value
Test method
Purity(in dry condition)
%
99.5

CE-55.4
arsenic
ppm

0.2
CE-93.1
Heavy metal content
ppm

10.0
CE-93.1
Lead content
ppm

2.0
CE-93.1
Mercury content
ppm

1.0
CE-93.1
Water content(in bag)
%

8.0
CE-7.1
Sodium carboxy acetic acid
%

0.40
CE-50.1
PH(1% water solution)
%
6.5
8.0
CE-8.1
Plate test
CFU/g

1000
CE-92.1
Sodium chloride content
%

0.40
CE-15.5
Na content
%
6.5
9.5
CE-59.5
replacement

0.65
0.85
CE-28.4
sulfate
%
20.0
33.3
CE-66.1
Total salt content(in dry condition)
%

0.50
CE-15.4
Viscosity(25℃,in dry condition, 1% water solution)
mPa.s
3000
4000
CE-5.15
Viscosity(viscometer : LVT, #4rotor, speed 30rpm)
mPa.s
3000
4000
CE-5.15
