Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder

Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder
Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder

Large Image :  Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder

Product Details:
Place of Origin: China
Brand Name: GELON
Certification: ce
Model Number: GN-SC90
Payment & Shipping Terms:
Minimum Order Quantity: 1KG
Price: USD230-270/kg
Packaging Details: Standard carton for export.
Delivery Time: 7-10 working days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 10000 kgs per month

Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder

Description
Production Name: Lithium Battery Research TernaryLithium Nickel Manganese Cobalt Oxide Cathode Material NMC Powder MOQ: 5KG
Sample: Yes Warranty: 3months-1 Year
Supply 1: Lithium Ion Battery Raw Material Supply 2: Lithium Ion Battery Production Equipment
Supply 3: Lithium Ion Solid State Battery Raw Material Tap Density ( G/cm 3 ): 1.20
Specific Surface Area ( ㎡ /g ): 0.85 Capaci Ty: 209.0 MAh/g
High Light:

solid state Cathode Material

,

nickel manganese cobalt oxide

,

NMC Powder

Lithium Battery Research TernaryLithium Nickel Manganese Cobalt Oxide Cathode Material NMC Powder



The product has strong applicability, good versatility, can be widely used in all kinds of cylindrical battery , Prismatic cell, polymer battery products.

Packing:25±0.01Kg/Pack

Storage: recommend Temperature≤30 ℃ , RT≤60%



Name Lithium Nickel Manganese Cobalt Oxide
Appearance Black Powder
Item standard Value
Tap Density ( g/cm3 )
1.2±0.2
1.20
SSA(m2/g)
0.90±0.25
0.85
H2O (ppm)
≤600
395
D10
1.9±0.9
1.56
D50
4.0±1.0
3.87
D90
7.5±2.5
8.00
D99
12.0±5.0
11.69
Li (wt% )
7.10±0.20
7.09
Ni (wt% )
54.00±1.50
53.86
Co  (wt% )
2.90±0.50
2.88
Mn (wt% )
2.20±0.50
2.71
CO3 2- (wt% )
0.3500
2233
OH(wt% )
0.4000
3081
Fe(ppm)
≤30
12
Cu(ppm)
≤30
6
Na(ppm)
≤200
60
Ca(ppm)
≤200
38
Mg(ppm)
≤150
66
Zn(ppm)
≤20
1
pH
≤12.30
11.89
capacity (mAh/g)
≥207.0
209.0
First discharge (%)
≥86.0
87.6



Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 0





We could supply one stop solution ( turn key project) for you.



1.Full set of lithium battery materials,including :

LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.





2.Full set of lithium battery equipments,for example:

mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.




Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 1











COMPANY PROFILE



Full Automatic Car Battery Production Line/ Electric Vehicle Battery Production Line/Li Ion Battery Plant Equipment
Integrate China's top materials manufacturer,Gelon can supply full set of raw materials solution for Lithium ion battery .



Our preponderant products are LFP,LMO,LCO, NMC,NCA; LTO,MCMB, natural graphite,Separator ,Electrolyte& Other accessories (SBR CMC NMP,PVDF,Sup-Li,Al&Ni Tabs ,and battery packs tags.,etc ) for new power lithium ion batteries.


Based on our extensive battery production experiences and battery equipments factrories,we can design and offer turn-key solution for customer, and indertake lithium ion battery project design, construction&training .


By now,Gelon group has successfully supplied automatic equipments formany well-known battery manufacturers,such as TESLA ,LG,SONY,ATL ......;

also successfully offered turn-key projects in Bolivia,Argentina,United Kingdom,Russia,Turkey, Thailand,Indonesia,Indian,South Africa ....





Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 2

Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 3

Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 4

Cathode Material Ternary Lithium Nickel Manganese Cobalt Oxide NMC Powder 5
