Prismatic Cell Vacuum Sealer Machine

Prismatic Cell Vacuum Sealer Machine
Prismatic Cell Vacuum Sealer Machine Prismatic Cell Vacuum Sealer Machine Prismatic Cell Vacuum Sealer Machine Prismatic Cell Vacuum Sealer Machine

Large Image :  Prismatic Cell Vacuum Sealer Machine

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-LW300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 45380/set
Packaging Details: Plywood box
Delivery Time: 30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 set per month

Prismatic Cell Vacuum Sealer Machine

Description
Product Name: Prismatic Cell Sealing Machine Aluminum Case Cap Laser Welding Machine Max. Output Power: 300W
Single Pulse Energy: 300W Wave Length: 1064mm
Pulse Width: ≤ 50ms Focal Spot Diameter: 1064NM
Laser Head: 36mm Series Function: Battery Cap Welding Machine
High Light:

Battery cap welding machine

,

Battery Laser Welding Machine

,

Prismatic Cell vacuum sealer machine

Prismatic Cell Sealing Machine Aluminum Case Cap Laser Welding Machine



GN-W300Y-SC-MT laser welding machine is a system integration equipment integrating light, machine and electricity, mainly used for the welding of prismatic cells’ cap and tab.

The equipment runs stably and reliably. The core laser is a 1500W pulsed YAG laser developed by our company. It has good processing quality, high efficiency, high-precision linear workbench, simple operation and convenient maintenance.



Using self-developed GN-W300Y-SC-MT pulsed laser, the fiber core diameter is 400µm, the length is 5 meters, the energy conversion efficiency is ≥3%, the host power is 10KW, the water cooler is 3KW, the single-point pulse laser energy is large, and the heat affected area is small.



Power
380V±5%, ≤ 10KW
Average output power
≤ 1500 W
Laser pulse width
0.5~10ms, adjustable in sections
Repetition frequency
1~150Hz adjustable in sections
Spot diameter
0.6~1.0ms
Power conversion efficiency
>90%
Overall conversion efficiency
>4 %
Continuous output energy instability
±1.5%
Continuous working time
≥24h
Service life of pulsed xenon lamp
≤10,000,000 times
Xenon lamp power
>6.0KW



Prismatic Cell Vacuum Sealer Machine 0

Prismatic Cell Vacuum Sealer Machine 1

Prismatic Cell Vacuum Sealer Machine 2

Prismatic Cell Vacuum Sealer Machine 3

Prismatic Cell Vacuum Sealer Machine 4
