Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-HS300V
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: USD 3000-6000/pc
Packaging Details: Wooden box
Delivery Time: 15-30 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 500pcs/month

523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer

Description
Color: Black Or Customize Powe Supply: AC220V/50Hz.110V/60Hz Or Customize
Vacuum Pump Capacity: ≥30m³/h Power: 1800W
Gas Source: 0.5~0.8MPa Argon, Nitrogen Cylinder, Or 0.7MPa Compressed Air Function: Pouch Cell Vacuum Presealing
High Light:

Pouch cell battery assembly line

,

vacuum sealing machine 1800W

,

523450 Pouch Cell Vacuum Sealer

Pouch Cell Battery Assembly Line Vacuum Sealing Machine 523450 Pouch Cell Vacuum Sealer



    This equipment is mainly suitable for vacuuming and hot-pressing packaging of flexible packaging (medium and small size) lithium batteries after liquid injection and standing; the head is made of copper material, which has good heat transfer effect, saves power consumption and improves work efficiency. Compared with similar products, it is more energy-saving; the pressure of the upper and lower heads can be adjusted by the pressure regulating valve to meet the requirements of different process parameters.

name Parameters Remarks
Upper/lower mold temperature up to 250°C Free temperature setting
degree of vacuum The highest is not lower than -95KPa adjustable
sealing time 0-99s adjustable
Edge time It is recommended to use 3~4s
Edge thickness 0~0.5mm
edge length 290mm
Sealable battery size Max L280mmxW280mm With air bag, with tabs
Edge width Max.6mm (5mm standard) Customized according to customer needs





523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 0523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 1523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 2523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 3523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 4523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 5523450 Pouch cell battery assembly line Vacuum Sealing Machine Vacuum Sealer 6
