Cylinder Cell Lithium Ion Battery Case 18650 / 26650 / 21700 / 32650 Empty Cell Cans

Large Image : Cylinder Cell Lithium Ion Battery Case 18650 / 26650 / 21700 / 32650 Empty Cell Cans

Product Details:

Place of Origin:	China
Brand Name:	Gelon
Certification:	Ce
Model Number:	GN-18650/21700/26650/32650

Payment & Shipping Terms:

Minimum Order Quantity:	100 Sets
Price:	USD0.3-0.6/ set
Packaging Details:	Standard Export Packaging.
Delivery Time:	5-8work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	10000sets per month

Contact Now

Cylinder Cell Lithium Ion Battery Case 18650 / 26650 / 21700 / 32650 Empty Cell Cans

Description

Product Name:	18650 Battery Case	Case:	18mm(OD) X 17.5mm(ID) X 67mm(H)
Top Insulator:	12.5mm(D) X 0.19mm(H)	Insulating:	PET
Top Cap:	17.5mm(D) X 4.05mm(H)	Cap Internal Resistance:	10~18
Bottom Insulator:	0~170 RPM Adjustable	Application:	Lithium Ion Battery Cylinder Cell Case
High Light:	Lithium Ion Battery Case 18650 , 21700 lithium battery case , Lithium Ion Battery Case 26650

Lithium battery case 18650/26650/21700/32650 Empty Cell Cans

1. Product Description

#Battery Case #Lithium battery case 18650/26650/21700/32650 #Cylinder Empty Cell Cans

Materials:
Case and cap are made of nickel plated A3 stell
Seal O-ring and spacer are made of nylon
Insulating gasket is made of PET
CAP :
Cap with Built-in PTC Thermistor for overcurrent protection
Material * Case and cap are made of Nickel plated A3 steel
* Seal O-rings are made of nylon
* Insulating gasket is made of PET

2. Product Parameters


			18650 cylinder cell cases

			Cap

			Cap with Built-in PTC Thermistor

Dimensions (Dia x Height)

			* Case: 18mm(OD) x 17.5mm(ID) x 67mm(H)

			* Top Cap: 17.5mm(D) x 4.05mm(H)

			* Top Insulator: 12.5mm(D) x 0.19mm(H)

			* Bottom Insulator: 12.5mm(D) x 0.19mm(H)

			Materials

			* case and cap made of Nickel plated A3 steel and seal O-ring made of nylon

			Weight

			9.50 g/pcs

			Note

			Safety valve's open pressure: 2.5MPa (the cap valve will open to release interior high pressure if over 2.5MPa to ensure no explosion from the can)

			21700 cylinder cell cases

			Dimensions (Dia x Height)

			* Case: 21.2mm (OD) x 20.7mm (ID) x 73.1mm (H)

			* Top Cap: 20.4mm (D) x 4.2mm (H)

			Materials

			* case and cap made of Nickel plated A3 steel and seal O-ring made of nylon

			Weight

			* 8.455 g/pcs

			Note

			* Safety valve's open pressure: 1.8 - 2.4MPa (the cap valve will open to release interior high pressure if over 2.4MPa, to ensure

			the can do not explode)

			26650 cylinder cell cases

			Dimensions (Dia x Height)

			* Case: 26mm(OD) x 25.5mm(ID) x 68mm(H)

			* Top Cap: 25.5mm(D) x 5mm(H)

			Materials

			* case and cap made of Nickel plated A3 steel and seal O-ring made of nylon

			Weight

			* 18.75 g/pcs

			Note

			* Safety valve's open pressure: 2.8MPa (the cap valve will open to release interior high pressure if over 2.8MPa to ensure no

			explosion from the can)

			32650 cylinder cell cases

			Dimensions (Dia x Height)

			* Case: 32mm(OD) x 31.5mm(ID) x 68mm(H)

			* Top Cap: 31.5mm(D) x 5.3mm(H)

			Materials

			* case and cap made of Nickel plated A3 steel and seal O-ring made of nylon

			Weight

			* 28.85g/pcs

			Note

			* Min. order: 60 pcs per package
