Battery Formation Lithium Ion Battery Tester

Battery Formation Lithium Ion Battery Tester

Battery Formation Lithium Ion Battery Tester

Battery Formation Lithium Ion Battery Tester

Battery Formation Lithium Ion Battery Tester

Large Image : Battery Formation Lithium Ion Battery Tester

Product Details:

Place of Origin:	China
Brand Name:	Gelon
Certification:	CE
Model Number:	GN- Lithium Ion Battery Tester

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$800.00 - $12,000.00/ set \|1 set/sets(Min. Order)
Packaging Details:	Standard exported package : Internal anticollision protection, external export wooden box packaging.
Delivery Time:	10days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000sets/month

Contact Now

Battery Formation Lithium Ion Battery Tester

Description

Place Of Origin:	Guangdong, China	Model Number:	GN-5V3A Battery Testers
Input Power:	AC 220 V ±10% / 50 Hz	AD,DAResolution:	AD:16bit DA:14bit
Input Resistance:	≥1MΩ	Per Channel Voltage Range:	Charge0V-5V;Discharge2.5V-5V
Stability:	±(0.05% Of Reading + 0.1% Of Range)	Stability 1:	≤0.1%
Per Channel Current Range:	Charge0A-20A;Discharge0A-20A
Highlight:	Lithium Ion Battery Tester 512 channels , 5v battery tester 3A , Lithium Ion Battery Tester CE

GELON Battery Formation Machine Battery Testing Machine Battery Tester with 512 Channels Battery Equipment

Product Overview

Battery Forming Machine :

Equipment application:After the battery is produced, it is charged for the first time to activate the active material in the battery and at the same time generate a dense film on the surface of the cathode electrode to protect the entire chemical interface. After the formation is completed, the battery can start normal charging and discharging.
Battery Grading Machine :

Equipment application:Charge and discharge the battery to detect the discharge capacity when the sub-capacity is fully charged to determine the capacity of the lithium battery. The data of each detection point is obtained through computer management, so as to analyze data such as battery capacity and internal resistance, and determine the quality level of the battery.

No	Item	Data
1	Model	5V 2A 512 channels 5V 3A 512 channels 5V 5A 256 channels
2	Voltage measurement range	0-5V, resolution 1mV
3	Battery voltage range	charging 0-4.5V; discharging 4.5-2V
4	Constant voltage range	2-4.5V
5	Voltage accuracy	±(0.1%RD+0.1%FS)
6	Current range	charging 0.01-2A; discharging 0.01-2A, resolution 1mA charging 0.015-3A; discharging 0.015-3A, resolution 1mA charging 0.025-5A; discharging 0.025-5A, resolution 1mA
7	Current accuracy	±(0.1%RD+0.1%FS)
8	Time range	arbitrarily set within 0-30000 minutes, the time unit is min
9	Fixture form	four-wire method fixture
10	Dimensions	1600 × 500 × 1840mm
11	Power supply	AC380V±150%, 50HZ

Battery Formation Lithium Ion Battery Tester 0

Battery Formation Lithium Ion Battery Tester 1
