High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material

Large Image : High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material

Product Details:

Place of Origin:	China
Brand Name:	Gelon
Certification:	CE
Model Number:	PVDF

Payment & Shipping Terms:

Minimum Order Quantity:	1kg
Packaging Details:	wooden box
Delivery Time:	7-10 working days
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	100,000kg/month

Contact Now

High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material

Description

PolyVinyliDene Fluoride (PVDF) Binder

PVDF is the standard binder material used in the production of composite electrodes for lithium-ion batteries.[11] Solution of PVDF 1−2% by mass in N-methyl-2-pyrrolidone (NMP) is mixed with an active lithium storage material such as graphite, silicon, tin, LiCoO2, LiMn2O4, or LiFePO4 and a conductive additive such as carbon black or carbon nanofibers. This slurry is cast onto a metallic current collector, and the NMP is evaporated to form a composite or paste electrode. PVDF is used because it is chemically inert over the potential range used and does not react with the electrolyte or lithium.

High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material 0

High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material 1

High Stability PVDF Binder 5130 HSV900 Polyvinylidene Fluoride Powder with 600,000 Molecular Weight for Lithium Ion Battery Material 2

Shape

White Powder

Purity

≥99.5%

Standard specific gravity

1.74~1.77

Dielectric constant

100MHz 4.50~5.50

100Hz 8.00~9.50

Melting Point

160-168 ℃

Melting Indix

1-2 g/10min

Solubility

Transparent and dissolvable

Rotation Viscosity

≥2000 mPa·S

Intrinsic Viscosity

1.0-2.0 dL/g

Moisture

≤ 0.1 %

Molecular Weight

600,000

We can supply full set of lithium ion battery materials and equipments.
1.)full set of lithium battery materials, including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials; Aluminum foil, copper foils, battery separator, etc.
2.)full set of lithium battery equipments ,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutting machine --winding machine--sealed machine, etc.
3.)full set of lithium battery technology
we can design the laboratory and production line,according to customer's request.
