Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing

Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing
Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing

Large Image :  Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing

Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN-6050 GN-6020
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 700usd-1100usd
Packaging Details: Standard export package
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 sets /month

Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing

Description
Name: Vacuum Oven Application: Baking Materials
Vacuum Pumpp: Optional
Highlight:

Lab Li Ion Battery Research

,

Lab Vacuum Dryer Oven

,

CE Li Ion Battery Research

Laboratory Oven Industrial Raw Material Drying Oven



Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 0



Ⅰ.Features

  • Radiant warm wall heating system provides optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.
  • 3" (7.6 cm) glass wool insulation prevents heat loss from working chamber.
  • Silicone door gasket and positive latch door maintain seal at all vacuum levels.
  • Exclusive polycarbonate safety shield protects door glass.
  • Easy-to-clean #304 stainless steel chamber interior.
  • Vacuum and air lines constructed with corrosion-resistant stainless steel tubing for optimum chamber cleanliness and long term performance.
Type

GN-6020



Power Supply Standard AC220V 50HZ, 110V can customize
Power 400W
Temperature Range

RT+10~250℃



Temperature resolution 0.1℃
Temperature fluctuation ±1℃
Vacuum <133Pa
Operating ambient temperature +5~40℃
Inner Chamber size(mm)W*D*H 300*300*275
Outside size(mm)W*D*H 605*490*450
Shelf one
Weight About 50kg
Timing range 0~9999min
Studio material Stainless steel liner






Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 1Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 2
Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 3
Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 4
Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 5
Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 6Vacuum Oven Laboratory Industrial Raw Material Drying Oven Battery Raw Material Processing 7
