Li-Ion Battery Test System For Coin Cell Cylinder Cell Pouch Cell

Large Image : Li-Ion Battery Test System For Coin Cell Cylinder Cell Pouch Cell

Product Details:

Place of Origin:	Shandong, China
Brand Name:	GELON
Certification:	CE
Model Number:	CN- Battery Tester

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	USD 900-1300/set
Packaging Details:	Standard Export Package
Delivery Time:	7-45 sky
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	99/set/moon

Contact Now

Li-Ion Battery Test System For Coin Cell Cylinder Cell Pouch Cell

Description

Product Name:	Battery Test System	Model Number:	5V 10mA /5V 20mA /5V 50mA
Brand Name:	Gelon	Current Range:	5uA~1mA ,1mA~10mA
Frequency:	10Hz	Power:	25W
Cycles:	65535	AC Input:	AC 220V±10% 50Hz
Accuracy:	± 0.05% Of FS	Rise Time:	1ms (0~Full Range)
1ms (0~Full Range):	≤ (365*24)hour/step
High Light:	Li-ion Battery Test System , Cylinder Cell lithium battery tester , Pouch Cell Test System

Li-ion Battery Test System Battery Analyzer Battery Tester for Coin Cell Cylinder Cell Pouch Cell
Product Description
 Product ApplicationThis is an 8-channel battery analyzer to analyze small coin cells and cylindrical batteries . Each channel of the analyzer has independent constant-current and constant-voltage source, which can be programmed and controlled by computer software. This system provides most applications in battery testing fields such as electrode materials research, battery performance test, small-scale battery formation, capability grading, battery pack testing, etc.

			SPECIFICATIONS

			AC Input

			AC 220V±10% 50Hz

			Power

			25W

Voltage

			Measuring Range

			Charge: 25mV~5V Discharge: 0mV~5V

			Discharge Min Voltage

			-5V

			Accuracy

			± 0.05% of FS

			Stability

			± 0.05% of FS

Current

			Each channel output Range

			1st range: 5uA~1mA 2nd range: 1mA~5mA
3rd range :5mA~10mA

			Accuracy

			± 0.05% of FS

			Constant voltage cut-off current

			1st range: 2uA 2nd range: 0.01mA

			3rd range :0.02mA

			Stability

			± 0.05% of FS

			Power

			Output Power Per Channel

			0.05W

			Stability

			± 0.1% of FS

			Time

			Rise Time

			500us

			Step Time

			≤ (365*24)hour/step Time Format 00:00:00.000 (h:min:s:ms)

			Data

			Acquisition

			Intervals

			Min. Time interval Δt:100ms

			Min. Voltage interval ΔU: 10mV

			Min. Current interval ΔI: 1st range: 2uA 2nd range: 0.01mA

			3rd range :0.02mA

			Frequency

			10Hz

			Charge

			Mode of Operation

			CCC, CVC, CC & CVC,CPC

			End Conditions

			Voltage, Current, Test Time, Capacity,-△V

			Discharge

			Mode of Operation

			CCD, CPD,CRD

			End Conditions

			Voltage, Current, Test Time, Capacity,-△V

			Cycle

			Cycles

			65535

			Steps

			254

			Nested Function

			Max three levels of loops

			Channel Features

			Independent pairs of closed loop for constant current source and constant voltage source

			Channels

			Independent control

			Number of Channels Per Cabinet

			8

Gelon LIB Group was set up as a manufacturer and exporter in 2007, dealing with lithium ion battery materials, equipments,production line,etc.

Integrate China's top materials manufacturer,Gelon can supply full set of raw materials solution for Lithium ion battery ,

Our preponderant products are LFP,LMO,LCO, NMC,NCA; LTO,MCMB, natural graphite,Separator ,Electrolyte& Other accessories (SBR, CMC ,NMP PVDF,Sup-Li,Al&Ni Tabs ,and battery packs tags.,etc ) for new power lithium ion batteries.

Based on our extensive battery production experiences and battery equipments factrories,we can design and offer turn-key solution for customer, and undertake lithium ion battery project design, construction&training.

By now, Gelon group have finished projects in Bolivia,Indonesia, Indian,Russia, United Kingdom,Turkey, Argentina,Thailand , South Africa and etc.

We have accumulated 15+ years experiences on lithium battery raw material production, battery manufacturing and equipment production. With our extensive experience and knowledge, we can provide our customers not only the premium products, but also the most professional service and technical support.

Lab cell production line	Volatage and Capacity Can be Customzied
Cylinder cell production line	Volatage and Capacity Can be Customzied
Pouch cell production line	Volatage and Capacity Can be Customzied
Automatic production line	Volatage and Capacity Can be Customzied

Full Automatic Car Battery Production Line/ Electric Vehicle Battery Production Line/Li Ion Battery Plant Equipment

Integrate China's top materials manufacturer,Gelon can supply full set of raw materials solution for Lithium ion battery .Our preponderant products are LFP,LMO,LCO, NMC,NCA; LTO,MCMB, natural graphite,Separator ,Electrolyte& Other accessories (SBR CMC NMPPVDF,Sup-Li,Al&Ni Tabs ,and battery packs tags.,etc ) for new power lithium ion batteries.

Based on our extensive batteryproduction experiences and battery equipments factrories,we can design and offer turn-key solution for customer, and indertakelithium ion battery project design, construction&training .

By now,Gelon group has successfully supplied automatic equipments formany well-known battery manufacturers,such as TESLA ,LG,SONY,ATL ......; also successfully offered turn-key projects in Bolivia,Argentina,United Kingdom,Russia,Turkey, Thailand,Indonesia,Indian,South Africa ....

Gelon Automatic Pouch Cell Production Line :

Li-Ion Battery Test System For Coin Cell Cylinder Cell Pouch Cell 4
