Product Details:
|
| Testing Speed: | 0.5seconds | Electric Source: | 220V±10% 50Hz |
|---|---|---|---|
| Consume Power: | Max 50W | Tester Size: | L(190mm)*W(153mm)*H(90mm) |
| Net Weight: | 3kg | Product Name: | Battery Testing Machine |
| Highlight: | 18650 Battery Test Machine,Battery Internal Resistance Tester,0.5seconds Battery Test Machine |
||
Applied environment:
1) Temperature: 0~40℃
2) Height application: less than 2KM elevation
3) RH: 40~80%RH
Measurement range:
1)voltage measurement range:
0-5V minimum resolution:1mV
0-50V minimum resolution:10mV
2)internal resistance measurement range:
0-40mΩ minimum resolution:0.01mΩ
0-400mΩ minimum resolution:0.1mΩ
0-4000mΩ minimum resolution:
| Testing speed | 0.5seconds |
| Electric source | 220V±10% 50Hz |
| Consume power | max 50W |
| Tester size | L(190mm)*W(153mm)*H(90mm) |
| Net weight | 1.5kg |
| Gross weight | 2kg |
