Product Details:
Place of Origin: China
Brand Name: Gelon
Certification: CE
Model Number: GN800
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: USD6300-6500/SET
Packaging Details: Wooden Case/Can Custom
Delivery Time: about 15days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000sets/month

Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine

Description
Frequency (KHz): 40 Nput Max Electric Power (VA): 800
Power: 220V±10%/can Custom Air Pressure (Mpa): 0.1-0.5
Time Control(S ): <1s NW(kg): 50-60
High Light:

Ultrasonic battery tab welder

,

battery tab spot welder

,

Automatic electrode welding machine

2022 Newest Battery Tab Welding Electrodes Automatic Packing Tabs Welder Ultrasonic Welding Machine



Ultrasonic welding Machine as a clean,high efficency ,precise
and economic welding technology , ultrasonic welding has
been widely used in many industries such as battery
production ,electronics ,appliances and auto manufacture etc.
No.
Frequency
(KHz)
Input Max
Electric
Power
(VA)
power
Air Pressure
(Mpa)
Time
control
(S)
(kg)
GN700 40 700 220V±10% 0.1-0.5
<1s
50-60
GN800 40 800 220V±10% 0.1-0.5
<1s
50-60
GN1000 25 1000 220V±10% 0.1-0.5
<1s
50-60
GN2000 20 2000 220V±10% 0.2-0.5
<1s
70-80
GN3000 20 3000 220V±10% 0.2-0.5
<1s
70-80
GN4000 20 4000 220V±10% 0.2-0.5
<1s
70-80
GN4500 20 4500 220V±10% 0.2-0.5
<1s
70-80
GN5000 20 5000 220V±10% 0.2-0.5
<1s
70-80
GN5500 20 5500 220V±10% 0.2-0.5
<1s
70-80
GN6000 20 6000 220V±10% 0.2-0.6
<1s
70-80
GN6500 20 6500 220V±10% 0.2-0.6
<1s
70-80
GN8000 20 8000 220V±10% 0.2-0.6
<1s
70-80
Remark:1,ultrasonic handpiece size(L*W*H):450*185*235mm 2,ultrasonic generator
size(L*W*H):465*210*600 mm 3,work table size:600*900*750mm

Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 0Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 1Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 2Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 3Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 4Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 5Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 6Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 7Ultrasonic Battery Tab Welder Automatic Electrodes Welding Machine 8

We supply:
1.Full set of lithium battery materials,including :
LiFePO4,LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and Other Cathode&Anode Battery Materials;Aluminum foil,Copper foils,Battery separator,etc.

2.Full set of lithium battery equipment,for example:
mixing machine --coating machine--vacuum oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.

3.Full set of lithium battery technology.
we can design the laboratory and production line according to customer's request.
