Product Details:
|
| Product Name: | Electrodynamic Vibration Testing System | Vibration Direction: | Vertical+Horizontal |
|---|---|---|---|
| MOQ: | 1 Set | Test Types: | Sine Sweep; Random; |
| Frequency Response Range: | 2 To 3000Hz | Max. Sine Force: | 300Kg.f Peak (3kN) |
| Max. Random Force: | 300Kg.f R.ms (3kN) | Max. Shock Force: | 600Kg.f Peak (6kN) |
| Frequency Range: | 1～4000Hz | Max. Displacement: | 38mm P-p |
| High Light: | Lithium Ion Battery Vibration Testing System,Vibration Battery Testing Equipment,4000Hz Battery Testing Equipment |
||
Electrodynamic Vibration Testing System Tester Battery Testing Equipment
Application:
Vibration test is a process of exciting or shocking some part or device to observe its reaction in real environment. Vibration test is widely applied in many fields, ranging from circuit board, airplane, ship, rocket, missile, automobile, household appliance and other industrial products.
Standard Compliance:
IEC62133;UN38.3;UL1642 and other national and international standards, including GB, GJB, UL, JIS, DIN, ISO, BS, MIL, IEC and ASTM standards.
| Max. velocity | 2.0m/s |
| Max. acceleration | 100G (980 m/s2) |
| Effective load | 120 kg |
| Diameter of armature | Ф150 mm |
| Vibration isolation frequency | 2.5 Hz |
| Flux leakage | ＜10gauss |
